MotoBatt Battery Snowmobile ARCTIC CAT 1985 to 2007 Tiger Shark, Bearcat, Cheetah, Cougar, Jag Liquid, Pantera, Panther, Prowler, Puma
ARCTIC CAT Tiger Shark (97-99) – 640CC
ARCTIC CAT Tiger Shark (97-99) – 770CC
ARCTIC CAT Bearcat 340, 440 (95-00) – 500CC
ARCTIC CAT Cheetah (91-93) – 500CC
ARCTIC CAT Cougar (91-94) – 500CC
ARCTIC CAT EXT (92-94) – 500CC
ARCTIC CAT EXT Special (91-92) – 500CC
ARCTIC CAT Jag AFS (89-91) – 500CC
ARCTIC CAT Jag AFS L/T (89-93) – 500CC
ARCTIC CAT Jag Liquid (96) – 500CC
ARCTIC CAT Jag Z (94) – 500CC
ARCTIC CAT Jag Z (93) – 500CC
ARCTIC CAT Jag, Jag Dix (94-99) – 500CC
ARCTIC CAT Jag, Jag Dix (85-93) – 500CC
ARCTIC CAT Lynx (91-93) – 500CC
ARCTIC CAT Pantera (86-93) – 500CC
ARCTIC CAT Panther (94-96) – 500CC
ARCTIC CAT Panther (89-93) – 500CC
ARCTIC CAT Panther 340 (97-00) – 500CC
ARCTIC CAT Panther 370 (01-07) – 500CC
ARCTIC CAT Panther 440 (97-03) – 500CC
ARCTIC CAT Prowler (90-93) – 500CC
ARCTIC CAT Puma (94-96) – 500CC
ARCTIC CAT Z (98-01) – 500CC
ARCTIC CAT Z 370, 440 (02-07) – 500CC
MB Item Number MBTX14AU
Voltage 12
CCA 210
Capacity (10HR) 16
Weight 5.4kg / 11.9lbs
Dimensions (in / mm) L: 5.31 (135) W: 3.54 (90) H: 6.61 (168)
Assembly Figure
Terminal Locations 4
Terminal 2, M6x2.5 (Part#MPT2)
Screws 4, M6x7 (Part#2xMPS2)
Allen Wrench 1, 4×4 (Part#MPAK2)
Terminal Caps 4, 12×5.5 (Part#2xMPC2)
Spacer 1, 8mm Bottom (Parts#MPBS6)
Case Color Yellow
Cap Style NA
Replaces YTX14AH, YTX14AHBS, YTX14AHLBS, YB14A1, YB14A2, YB14AA, YB14AA1, YB14AA2, YB14B1, YB14B2, YB14LA1, YB14LA2, YB14LB1, YB14LB2, YB14LA2S, SYB14LA2, SYB14LB2, 12N143A, 12N143B
